Microminiature Connectors
MDMH Hermetic
Our MDMH Hermetic Microminiature Connectors are ideal for applications that require more
robust sealing than can be achieved with epoxy resins. The MDMH uses size 24 AWG contacts
that are compression glass sealed through a steel shell and into a diallyl pthalate front-end
insulator. When mated, an interfacial seal provides environmental protection. We recommend
MDMH Hermetic receptacles be soldered to the chassis or container for a completely leak-proof
joint. MDMH Hermetic receptacles mate with standard MDM plugs.
Specifications
Standard materials & finishes
Shell
Insulator
Mild steel, tin-lead plated
Glass filled diallyl phthalate per MIL-M-14. Type SDGF
Contacts
Copper alloy, gold plated sockets on mild steel gold plated pins. Solder pots - mild steel gold plated
Compression glass
Hermetic seal
Leak rate
1 micron cubic ft/hr max (1.04 x 10-5 cc/sec at 1 ATM pressure differential)
ELECTRICAL DATA
No. of contacts
Dielectric withstanding voltage
Insulation resistance
Wire size
9 to 100
150 VAC
5000 Mohm minimum
#26 through #30 AWG
Solder pot
Contact termination
MECHANICAL FEATURES
Size or length
8 sizes
Service class
Hermetically sealed
Friction/jacks
Coupling
Polarization
Keystone shaped shells
.050 (1.27) centers
Receptacle, solder mount
Contact spacing
Shell style
How to Order
MDMH
-
51
S
S
Hermetic Micro D Receptacle Series
Contact layout 9, 15, 21, 25, 31, 37, 51, 100
Socket Contacts (only)
Termination type
Dimensions shown in mm
Specifications and dimensions subject to change
www.ittcannon.com
36
