Micro-D Metal Shell - .050” Contact Spacing
Mounting Hardware Views (for size 100)
MDM
#4-40 UNC-2A THD
#4 LOCK WASHER
PANEL -
.123 ± .005
(3.12 ± 0.13) DIA.
#4-40 UNC-2B
THD
MAY BE USED WITH
.093 (2.36) MAX
THICK PANEL
+.010
-.005
180
(4.57
.500 (12.70)
MAX.
B
.064 ± .010
(1.62 ± 0.25) TYP.
+.025
-0.13
)
.235 ± .005
(5.97 ± 0.13)
.185 (4.70)
MAX.
A
.395 (10.03)
MAX.
MATING SIDE
#4-40 UNC-2B NOTHING OR FEMALE THD
Jackpost - (P)
90° Angle Mounting Bracket
A
B
Max.
Description
Part Number
+/-.005 (±0.13)
Screw
322-9500-000
320-9505-000
015-9516-002
015-9516-003
N/A
N/A
Jackpost kit
Mounting Bracket 90° MDM for 9 thru 37 Shell Sizes
Mounting Bracket 90° MDM for 51 Shell Size
.147 (3.73)
.169 (4.29)
.308 (7.82)
.350 (8.89)
This hardware is factory installed.
MATING
FACE
.014 ± .004
(0.36 ± 0.10) ALLOWABLE
DIAMETRAL FLOAT
.020 (0.51) MAX. ALLOWABLE
AXIAL FLOAT
.735 (18.67)
MAX.
CONNECTOR
SHOWN FOR
REF. ONLY
.174 ± .005
(4.4 ± .10)
HEX. SOCKET HEAD.
.078 (1.98) ACROSS FLATS
.050 (1.27) MIN. DEPTH
.185 (4.70)
.155 (3.94) MAX.
.093
(2.36)
REF.
MAX
.040 (1.02) MAX.
AXIAL FLOAT
.116 ± .002
(2.29 ± .051)
DIA
.031 ± .003
PART HAS A .040 (1.02)
MAX AXIAL FLOAT
#4-40
UNC-2A
THD
MATING
FACE
(0.79 ± 0.08)
#4-40 UNC-2A THD
MATING SIDE
Jackscrew - (K) Standard
Float Mount - (F) Std.
Jackscrew - (L) (Low Profile)
*NOTE: Torque values are as follows:
Low Profile Jackscrew (L)-4.0 in-lbs
Standard Profile Jackscrew (K)-4.0 in-lbs
Jackpost Bushing (for Rear Panel Mounting)
Dimensions for Rear Panel Mounting
ENGAGING FACE
3/16" HEX.
A
LOCKING POST
1.800 ± .005
(45.72 ± 0.13)
Panel
Thickness
Jackpost Kit
Number*
#4-40 UNC-2B
+.005 (0.13)
-.000 (0.00)
.185 (4.70)
.170 (4.32)
+.004
-.000
3/32 (2.4)
1/16 (1.6)
1/32 (0.8)
3/64 (1.2)
.087 (2.21)
.058 (1.42)
.025 (0.64)
.042 (1.07)
320-9505-013
320-9505-012
320-9505-010
320-9505-011
.401
A
)
+1.10
-0.00
(10.18
.500 (12.70)
MAX.
.161 (4.09)
.159 (4.04)
+.004
-.000
DIA.
1.516
+1.10
-0.00
)
(38.51
RECEPTACLE
FOR REF. ONLY
+.005
-.000
.125
R
*2 jackposts, 2 nuts, 2 washers
Torque value for size 100
)
+0.13
-0.00
(3.18
#4-40 THREAD
RETAINING NUT
Note: Size 100 requires B mounting hole shell
size when using rear panel mount jackposts
Dimensions shown in mm
Specifications and dimensions subject to change
