Basic - Hydraulic - Electrically driven tool - Version A
Basic - Hydraulic - Manual Operated tool - Version B
Pump Handle with
Reset Function
H- Crimp
Head
Handle
H- Crimp Head
Electro-Hydraulic
Foot pedal
Aggregat EHA2 - ITT
Basic – Manual operated crimp tool – Version C
Version
Description
Marking
Part Number
121586-5253
121586-5257
995-0001-585
A
B
C
Electro-Hydraulic - Aggregat with footpedal
Manually operated Hydraulic handtool
Hand Crimp Tool
HP400EL-ITT
HPW400U-ITT
M22520-1-01
Crimp tool and Bench mount
Foot pedal
Gauge
Description
Marking
WA27F-CE
BM-2
Part Number
121586-5067
121586-5068
121586-5069
995-0001-684
Pneumatic crimp tool (AWG 12 - 20)
Bench mount
Foot pedal
Gauge
WA10
M22520-3-1
Crimp Dies
Cable Size
AWG
Product
Contact Size
Part Number
Hex. Diameter
Stamped label
mm2
6/10
16
60/100/8
160/4
121586-5231
121586-5230
121586-5229
121586-5232
5,20
7,25
11,40
01
02
03
8
4
0
Crimp die
Locator
500/0
50
MS / CA
Notes
1. For large series production, semi-automatic crimp machine
Type HACS-IV-MSXX upon request
2. For insertion and extraction of the contacts and for connector
assembly, see Assembly Instructions MIL-C-5015/VG95234
3. Standard contacts acc. to MIL-C-5015/VG95234
Crimp die with locator
Crimp die
Locator
* Datasheet available upon request
Dimensions shown in mm
Specifications and dimensions subject to change
www.ittcannon.com
61
