D Subminiature
Straight Solder Termination (Stamped)
Plug
Part Numbers
Shell Size
DE
DA
DB
DC
DD
Layout
9
15
25
37
50
Through Hole
ZDE9P-OL2
ZDA15P-OL2
ZDB25P-OL2
ZDC37P-OL2
ZDD50P-OL2
ZD*
Standoff With
Boardlock
ZDEE9P-OL2-146
ZDAE15P-OL2-146
ZDBE25P-OL2-146
ZDCE37P-OL2-146
ZDDE50P-OL2-146
Selection Guide
For Product Features, Specifications,
Materials and Finishes, see pages 2-3.
Reader’s Resource
For contact cavity arrangements,
see page 224.
For P.C. hole patterns, see page 274.
For panel cutouts, see page 221.
For hardware views (Standard), see page 226.
Engaging Face
A
C
B
POSITION 1
E
D
10°
0,64 (.025)
REF
3,18 (.125)
MIN
4,32 (.170)
REF
2,84 (.112)
6,00
(.236)
STANDOFF
# 4-40 UNC
1,00 (.040)
REF
W
F
Hardware removed for clarity
Dimensions
Shell Size
DE
DA
DB
DC
DD
A
±0,38
(.015)
30,81 (1.213)
39,14 (1.541)
53,04 (2.088)
69,32 (2.729)
66,93 (2.635)
B
±0,13
(.005)
16,92 (.666)
25,25 (.994)
38,96 (1.534)
55,42 (2.182)
52,81 (2.079)
C
±0,13
(.005)
24,99 (.984)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
61,11 (2.406)
D
±0,13
(.005)
8,36 (.329)
8,36 (.329)
8,36 (.329)
8,36 (.329)
11,07 (.436)
E
±0,38
(.015)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
15,37 (.605)
F
±0,25
(.010)
10,72 (.422)
10,72 (.422)
10,82 (.426)
10,82 (.426)
10,82 (.426)
W
±0,368
(.0145)
6,693 (.2635)
6,693 (.2635)
—
—
—
W
±0,41
(.016)
—
—
6,84 (.269)
6,84 (.269)
6,84 (.269)
8
Dimensions are shown in mm (inch)
Dimensions subject to change
