D Subminiature
Combo D
Straight PC Tails — European (Sizes DE-DD)
Receptacle
Part Numbers
Part Number
X
4.60 (.181)
Part Number
X
6.05 (.238)
Shell Size
DE
Layout
5W1
DEM-5W1S-OL2-A197
DAM-7W2S-OL2-A197
DAM-11W1S-OL2-A197
DAM-3W3S-OL2-A197
DAM-3WK3S-OL2-A197
DBM-5W5S-OL2-A197
DBM-9W4S-OL2-A197
DBM-13W3S-OL2-A197
DBM-17W2S-OL2-A197
DBM-21W1S-OL2-A197
DCM-8W8S-OL2-A197
DCM-13W6S-OL2-A197
DCM-17W5S-OL2-A197
DCM-21WA4S-OL2-A197
DCM-25W3S-OL2-A197
DCM-27W2S-OL2-A197
DDM-24W7S-OL2-A197
DDM-36W4S-OL2-A197
DDM-43W2S-OL2-A197
DDM-47W1S-OL2-A197
DEM-5W1S-OL4-A197
DAM-7W2S-OL4-A197
DAM-11W1S-OL4-A197
DAM-3W3S-OL4-A197
DAM-3WK3S-OL4-A197
DBM-5W5S-OL4-A197
DBM-9W4S-OL4-A197
DBM-13W3S-OL4-A197
DBM-17W2S-OL4-A197
DBM-21W1S-OL4-A197
DCM-8W8S-OL4-A197
DCM-13W6S-OL4-A197
DCM-17W5S-OL4-A197
DCM-21WA4S-OL4-A197
DCM-25W3S-OL4-A197
DCM-27W2S-OL4-A197
DDM-24W7S-OL4-A197
DDM-36W4S-OL4-A197
DDM-43W2S-OL4-A197
DDM-47W1S-OL4-A197
DA
DA
DA
DA
DB
7W2
11W1
3W3
3WK3ឮ
5W5
DB
9W4
DB
13W3
17W2
21W1
8W8
DB
Reader’s Resource
ɀ For contact cavity arrangements,
see page 223.
ɀ For P.C. hole patterns, see pages 269-271.
ɀ For panel cutouts, see page 221.
ɀ For hardware views (European),
see page 227.
DB
DC
DC
13W6
17W5
21WA4
25W3
27W2
24W7
36W4
43W2
47W1
DC
DC
DC
DC
DD
DD
DD
DD
Note: Performance class 3 standard, for performance class 2 add -A191. Example: DEM-5W1S-OL2-A191-A197
ឮ Keyed.
DD Configuration
5,69
(.224)
Engaging Face
2,84
(.112)
A
B
C
Ø 3,05
(.120)
K
D
E
L
10°
2,84
(.112)
Ø 0,60
(.024)
X
F
W
Dimensions
A
B
C
D
E
F
W
K
L
Shell Size
DE
0,38 (.015)
30,81 (1.213)
39,14 (1.541)
53,04 (2.088)
69,32 (2.729)
66,93 (2.635)
0,13 (.005)
16,33 (.643)
24,66 (.971)
38,38 (1.511)
54,84 (2.159)
52,42 (2.064)
0,13 (.005)
0,13 (.005)
7,90 (.311)
7,90 (.311)
7,90 (.311)
7,90 (.311)
10,74 (.423)
0,38 (.015)
0,25 (.010)
0,38 (.015)
6,94 (.273)
6,94 (.273)
6,94 (.273)
6,94 (.273)
6,94 (.273)
0,318 (.0125)
1,206 (.0475)
1,206 (.0475)
1,206 (.0475)
1,206 (.0475)
1,206 (.0475)
0,25 (.010)
24,99 (.984)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
61,11 (2.406)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
15,37 (.605)
10,90 (.429)
10,90 (.429)
10,90 (.429)
10,90 (.429)
10,90 (.429)
0,76 (.030)
0,76 (.030)
0,76 (.030)
0,76 (.030)
0,76 (.030)
DA
DB
DC
DD
Dimensions are shown in mm (inch)
Dimensions subject to change
