D Subminiature
Combo D
3C3 Shielded Special — Receptacle only
Receptacle
Materials and Finishes
Part Number
Body Material:
Body Finish:
Zinc
Tin
DAM53512-1405
Coaxial Center
Contact Finish:
30 Ȗ inches Gold
Note: For additional materials and finishes, see introduction
page 43.
Reader’s Resource
ɀ For contact cavity arrangements,
see page 223.
ɀ For P.C. hole patterns, see page 231.
ɀ For panel cutouts, see page 221.
Engaging Face
A
B
C
D
E
0,56
(.023)
10°
Ø 0,51
(.020)
4,19 - 2,79
(.165 - .110)
2,54
(.100)
12,12
(.477)
12,62
(.497)
F
9,37
(.369)
W
Note: Connector supplied with boardlocks.
Dimensions
A
B
C
D
E
F
W
Shell Size
0,38 (.015)
0,13 (.005)
0,13 (.005)
0,13 (.005)
0,38 (.015)
0,25 (.010)
0,25 (.010)
DA
39,14 (1.541)
24,66 (.971)
33,32 (1.312)
7,90 (.311)
12,55 (.494)
10,90 (.429)
6,17 (.243)
Dimensions are shown in mm (inch)
Dimensions subject to change
49
ITT [ ITT Cannon ]
