D Subminiature
Combo D
Cable (Size 8) Loose Contacts — High Power — Solder
Plug
Part Number
Part Number
Wire
Size
Gold Over Nickel
50Ȗ in. Gold over Ni
Current Rating
40 A
DM53745-1
DM53745-7
DM53745-8
DM53745-28
DM53745-27
DM53745-25
8 AWG
12 AWG
16 AWG
20 A
10 A
Receptacle
Part Number
Part Number
Wire
Size
Gold Over Nickel
50Ȗ in. Gold over Ni
Current Rating
40 A
DM53744-1
DM53744-6
DM53744-7
DM53744-21
DM53744-25
DM53744-24
8 AWG
12 AWG
16 AWG
20 A
10 A
Cable (Size 8) Loose Contacts — High Power — Crimp
Plug
Recommended Wire Trim Length
Part Number
Part Number
Part Number
XA
XB
Current
Rating
Wire
Size
Gold Over Nickel
DM130338-4
DM130339-4
DM130340-4
30Ȗ in. Gold over Ni 50Ȗ in. Gold over Ni
max.
max.
DM130338
DM130339
DM130340
DM130338-1
DM130339-1
DM130340-1
4,60 (.181)
2,54 (.100)
1,07 (.067)
5,84 (.230)
5,54 (.218)
2,59 (.102)
40 A
20 A
10 A
8 AWG
12 AWG
16 AWG
Receptacle
20,93 - 20,42
(.824 - .804)
Recommended Wire Trim Length
Ø B Ø A
Part Number
Gold Over Nickel
Part Number
Part Number
XA
max.
XB
max.
Current
Rating
Wire
Size
30Ȗ in. Gold over Ni 50Ȗ in. Gold over Ni
DM130341-4
DM130342-4
DM130343-4
DM130341
DM130342
DM130343
DM130341-1
DM130342-1
DM130343-1
4,60 (.181)
2,54 (.100)
1,07 (.067)
5,84 (.230)
5,54 (.218)
2,59 (.102)
40 A
20 A
10 A
8 AWG
12 AWG
16 AWG
High Power Crimp Tooling
M300-BT
Crimp Tool/Locator
Wire
Size
Crimp
Tool
Tool Setting
Number
Locator
TP968
TP968
TP968
TH554
TH554
8 AWG
10 AWG
M300-BT
M300-BT
M300-BT
FT-8
6
5
1
6
5
12/14 AWG
16 AWG
18 AWG
FT-8
Dimensions are shown in mm (inch)
Dimensions subject to change
