D Subminiature
Combo D
Crimp (Size 20) Contacts
Loose Contacts
Pin Contact
Socket Contact
Stamped contacts with insulation support are
supplied loose for use with hand crimp tooling.
Two sizes are available to accommodate wire
ranges 20 - 26 AWG.
Part Number
Pin Contact
Part Number
Socket Contact
Finish
30Ȗ inches Gold over Nickel
For tooling, see this page.
24-26 AWG
030-2487-017
20-24 AWG
24-26 AWG
20-24 AWG
030-2487-016
030-2488-017
030-2488-016
Reeled Contacts (5,000 Pieces per Reel)
Stamped contacts with insulation support are
supplied on reels of 5,000 for use with semi-
automatic strip and crimp machines. Two sizes are
available to accommodate wire ranges 20 - 26
AWG.
Pin Contacts
Socket Contacts
Part Number
Pin Contact
Part Number
Socket Contact
Finish
Gold over Nickel
24-26 AWG
980-2000-925
980-2000-946
20-24 AWG
980-2000-924
980-2000-945
24-26 AWG
980-2000-926
980-2000-944
20-24 AWG
980-2000-923
980-2000-943
30Ȗ inches Gold over Nickel
For semi-automatic tooling, see page 275.
Pin Contacts
Socket Contacts
Tooling
CCT-D*A-1
Hand Crimp Tool
Description
CCT-D*A-1
Part Number
995-2000-000
Extraction Tool
Description
Part Number
980-0008-135
980-0008-136
Wire Size
CIET-D*A-20-24
CIET-D*A-24-26
20-24 AWG
24-26 AWG
For semi-automatic tooling, see page 275.
Dimensions are shown in mm (inch)
Dimensions subject to change
83
ITT [ ITT Cannon ]
