D Subminiature
Combo D
Shield Cans
Ferrule
Ferrule
Crimp Tool
Crimp Tool
Position
X Cable
4,8 - 5,5
5,5 - 6,2
6,2 - 7,2
7,2 - 8,2
8,2 - 9,5
9,5 - 11,1
X A
Part Number
Part Number
6,25 (.246)
6,25 (.246)
8,20 (.323)
8,20 (.323)
11,50 (.452)
11,50 (.452)
304-8810-000
304-8810-000
304-8811-000
304-8811-000
304-8812-000
304-8813-000
D115433-1
D115433-1
D115433-2
D115433-2
D115433-3
D115433-3
B
A
B
A
B
A
Part Numbers
Materials and Finishes
Shield Can and Ferrule
Material:
Top Can (B size):
348-8946-000
Bottom Can (B size): 348-8945-000
Steel
Note: For other available can sizes, consult factory for details.
Finish:
Tin
ɀ Order 1 top can, 1 bottom can, 1 ferrule per
connector.
FERRULE
CABLE
Ø 10,00 (.394)
10,10 (.398)
Ferrule
Wire Trim Dimensions
Crimp Tool Positions
11,25(.443)
Ø A
Ø 11,10(.437)
10,00(.394)
50,00 (1.969)
Dimensions are shown in mm (inch)
Dimensions subject to change
82
