D Subminiature
Combo D
Crimp Cable Connectors without Contacts (Sizes DA-DD)
Plug
Part Numbers
Shell Size
Layout
7W2
Part Number
DA
DA
DA
DB
DB
DB
DB
DB
DC
DC
DC
DD
DD
DAA7W2PK87F0
DAA11W1PK87F0
DAA3W3PK87F0
DBA5W5PK87F0
DBA9W4PK87F0
DBA13W3PK87F0
DBA17W2PK87F0
DBA21W1PK87F0
DCA8W8PK87F0
DCA21WA4PK87F0
DCA25W3PK87F0
DDA24W7PK87F0
DDA36W4PK87F0
11W1
3W3
5W5
9W4
13W3
17W2
21W1
8W8
Reader’s Resource
ɀ For contact cavity arrangements,
see page 222.
ɀ For panel cutouts, see page 221.
21WA4
25W3
24W7
36W4
Note: For crimp (Size 20) contacts and tooling, see pages 83 & 275.
L
10,92 (.430)
MAX
K
Engaging Face
A
C
B
10°
D
E
Dimensions
A
B
C
D
E
F
W
W
K
K
L
Shell Size
DE
0,38 (.015)
0,13 (.005)
0,13 (.005)
24,99 (.984)
33,32 (1.312)
0,13 (.005)
0,38 (.015)
0,25 (.010)
0,368 (.0145)
0,41 (.016)
0,317 (.0125)
0,25 (.010)
0,25 (.010)
30,81 (1.213) 16,92 (.666)
39,14 (1.541) 25,25 (.994)
8,36 (.329)
8,36 (.329)
8,36 (.329)
8,36 (.329)
11,07 (.436)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
15,37 (.605)
10,72 (.422)
10,72 (.422)
10,82 (.426)
10,82 (.426)
10,82 (.426)
6,693 (.2635)
—
1,206 (.0475)
—
0,76 (.030)
0,76 (.030)
0,99 (.039)
0,99 (.039)
0,99 (.039)
DA
6,693 (.2635)
—
1,206 (.0475)
—
DB
53,04 (2.088) 38,96 (1.534) 47,04 (1.852)
69,32 (2.729) 55,42 (2.182) 63,50 (2.500)
66,93 (2.635) 52,81 (2.079) 61,11 (2.406)
—
—
—
6,84 (.269)
6,84 (.269)
6,84 (.269)
—
—
—
1,52 (.060)
1,52 (.060)
1,52 (.060)
DC
DD
Dimensions are shown in mm (inch)
Dimensions subject to change
