ARINC 600
BKAD/E/F
Sealing Plugs-BKAE Environmental Connectors Only
P/N 225-0090-000
Material: Teflon
(All others thermoplastic)
Part
Number
Contact
Size
Color
A
B
C
22
Black
.063 (1.6)
.040 (1.0)
.469 (11.9)
225-1013-000
225-0070-000
225-0071-000
20
16
12
Red
Blue
.085 (2.2)
.115 (2.9)
.171 (4.3)
.065 (1.6)
.075 (1.9)
.121 (3.1)
.469 (11.9)
.469 (11.9)
.564 (14.3)
Yellow
225-0072-000
225-0090-000
White
.365 (9.3)
.287 (7.3)
.835 (21.2)
#5 and #9 Coax
B
B
A
A
C
C
Filler Plugs-BKAD Non-Environmental Connectors Only
P/N 225-0099-000
Material: Teflon
(All others thermoplastic)
Part
Number
Contact
Size
Color
A
B
C
225-0094-000
22
Black
.069 (1.7)
.051 (1.3)
.420 (10.7)
225-0095-000
225-0096-000
225-0097-000
20
16
12
Red
Blue
.083 (2.1)
.131 (3.3)
.187 (4.7)
.069 (1.7)
.108 (2.7)
.156 (4.0)
.350 (8.9)
.320 (8.1)
.320 (8.1)
Yellow
B
A
B
A
#5 Coax
(Pin)
White
White
.275 (7.0)
.275 (7.0)
.251 (6.4)
.251 (6.4)
.450 (11.4)
225-0098-000
225-0099-000
C
#5 and #9 Coax
(Socket)
C
1.061 (26.9)
BKAF P/N 225-1058-000
(Size 22 - Black)
(See Customer Use Drawing for details)
Cavity Reducer
#5 Coax to #12 Contact
Cavity reducers are available when additional circuits are required for siz 12 power contacts. These
reducers, having the internal configuration of size 12 power contact, are inserted into the size 5 coaxial
insulator cavity to create size 12 power contact cavity.
Pin
Socket
P/N 021-8756-000
P/N 021-8757-000
(Non removable)
Dust Caps
Part Number
Description
Part Number
Description
Conductive dust caps protect against
static electricity.
025-1121-001
025-1122-001
025-1123-001
025-1124-001
BKAD 1-A & B-Plug
BKAD 1-C-Plug
025-1155-001
025-1156-001
025-1157-001
025-1158-001
BKAD 1-A&B-Receptacle
BKAD 1-C-Receptacle
BKAD 2&3-A & B-Plug
BKAD 2&3-C-Plug
BKAD 2&3-A & B-Receptacle
BKAD 2&3-C-Receptacle
Note: Supplied as standard for BKA product line only.
Dimensions shown in inch (mm)
Specifications and dimensions subject to change
www.ittcannon.com
19
