IRS2092
Lead Definitions: IRS2092
Pin #
1
2
Symbol
VAA
GND
IN-
Description
Floating input positive supply
Floating input supply return
Analog inverting input
3
COMP
CSD
VSS
VREF
OCSET
DT
Phase compensation input, comparator input
Shutdown timing capacitor
Floating input negative supply
5V reference voltage to program OCSET pin
Low side over current threshold setting
Deadtime program input
4
5
6
7
8
9
COM
LO
VCC
VS
HO
VB
Low side supply return
Low side output
Low side supply
High side floating supply return
High side output
10
11
12
13
14
15
16
High side floating supply
High side over current sensing input
CSH
Lead Assignments
1
2
3
4
5
6
16
15
14
13
12
11
VAA
GND
CSH
VB
HO
IN-
COMP
CSD
VS
VCC
LO
VSS
VREF
OCSET
7
8
10 COM
DT
9
PDIP16 and SOIC16N
www.irf.com
© 2007 International Rectifier
13
