IRFZ48R
Electrical Characteristics @ TJ = 25°C (unless otherwise specified)
Parameter
Min. Typ. Max. Units
60 ––– –––
Conditions
VGS = 0V, ID = 250µA
V(BR)DSS
Drain-to-Source Breakdown Voltage
V
∆V(BR)DSS/∆TJ Breakdown Voltage Temp. Coefficient ––– 0.060 ––– V/°C Reference to 25°C, ID = 1mA
RDS(on)
VGS(th)
gfs
Static Drain-to-Source On-Resistance
Gate Threshold Voltage
––– ––– 0.018
Ω
V
S
VGS = 10V, ID = 43A
VDS = VGS, ID = 250µA
VDS = 25V, ID = 43A
2.0
27
––– 4.0
Forward Transconductance
––– –––
––– ––– 25
––– ––– 250
––– ––– 100
––– ––– -100
––– ––– 110
––– ––– 29
––– ––– 36
V
DS = 60V, VGS = 0V
VDS = 48V, VGS = 0V, TJ = 150°C
VGS = 20V
IDSS
Drain-to-Source Leakage Current
µA
nA
Gate-to-Source Forward Leakage
Gate-to-Source Reverse Leakage
Total Gate Charge
IGSS
VGS = -20V
ID = 72A
Qg
Qgs
Qgd
td(on)
tr
Gate-to-Source Charge
Gate-to-Drain ("Miller") Charge
Turn-On Delay Time
Rise Time
nC VDS = 48V
VGS = 10V, See Fig. 6 and 13
–––
8.1 –––
VDD = 30V
––– 250 –––
––– 210 –––
––– 250 –––
ID = 72A
ns
td(off)
tf
Turn-Off Delay Time
Fall Time
RG = 9.1Ω
RD = 0.34Ω, See Fig. 10
Between lead,
6mm (0.25in.)
from package
D
LD
LS
Internal Drain Inductance
Internal Source Inductance
–––
–––
4.5 –––
–––
nH
G
7.5
and center of die contact
VGS = 0V
S
Ciss
Coss
Crss
Input Capacitance
––– 2400 –––
––– 1300 –––
––– 190 –––
Output Capacitance
VDS = 25V
Reverse Transfer Capacitance
pF
ƒ = 1.0MHz, See Fig. 5
Source-Drain Ratings and Characteristics
Parameter
Continuous Source Current
(Body Diode)
Min. Typ. Max. Units
Conditions
MOSFET symbol
showing the
D
IS
50*
––– –––
A
G
ISM
Pulsed Source Current
(Body Diode)
integral reverse
––– ––– 290
S
p-n junction diode.
VSD
trr
Diode Forward Voltage
Reverse Recovery Time
Reverse Recovery Charge
Forward Turn-On Time
––– ––– 2.0
––– 120 180
––– 0.50 0.80
V
TJ = 25°C, IS = 72A, VGS = 0V
TJ = 25°C, IF = 72A
ns
Qrr
ton
µC di/dt = 100A/µs
Intrinsic turn-on time is negligible (turn-on is dominated by LS+LD)
Notes:
ISD ≤ 72A, di/dt ≤ 200A/µs, VDD ≤ V(BR)DSS
TJ ≤ 175°C
,
Repetitive rating; pulse width limited by
max. junction temperature. ( See fig. 11 )
Pulse width ≤ 300µs; duty cycle ≤ 2%.
VDD = 25V, Starting TJ = 25°C, L = 22µH
RG = 25Ω, IAS = 72A. (See Figure 12)
* Current limited by the package, (Die Current = 72A)
2
www.irf.com
