Thermal Specifications and Design Considerations
The case temperature is defined at the geometric top center of the processor. Analysis
indicates that real applications are unlikely to cause the processor to consume
maximum power dissipation for sustained time periods. Intel recommends that
complete thermal solution designs target the Thermal Design Power (TDP) indicated in
Table 26 instead of the maximum processor power consumption. The Thermal Monitor
feature is designed to protect the processor in the unlikely event that an application
exceeds the TDP recommendation for a sustained periods of time. For more details on
the usage of this feature, refer to Section 5.2. In all cases the Thermal Monitor
Feature must be enabled for the processor to remain within specification.
Table 26.
Processor Thermal Specifications for 775_VR_CONFIG_05A Processors
Thermal
Processor
Number
Core Frequency
(GHz)
Minimum
Design
Maximum TC (°C)
Notes
T
C (°C)
Power (W)
1, 2
1, 2
1, 2
356
352
347
3.33
3.2
86
86
86
5
5
5
See Table 28 and
Figure 12
3.06
NOTES:
1. Thermal Design Power (TDP) should be used for processor thermal solution design targets. The TDP is not the
maximum power that the processor can dissipate.
2. This table shows the maximum TDP for a given frequency range. Individual processors may have a lower TDP.
Therefore, the maximum T will vary depending on the TDP of the individual processor. Refer to thermal profile
C
figure and associated table for the allowed combinations of power and T .
C
Table 27.
Processor Thermal Specifications for 775_VR_CONFIG_06 Processors
Thermal
Processor
Number
Core Frequency
(GHz)
Minimum
Design
Maximum TC (°C)
Notes
T
C (°C)
Power (W)
1, 2
1, 2
1, 2
1, 2
1, 2
365
360
356
352
347
3.66
3.46
3.33
3.2
65
65
65
65
65
5
5
5
5
5
See Table 29 and
Figure 13
3.06
NOTES:
1.
Thermal Design Power (TDP) should be used for processor thermal solution design targets. The TDP is not the maximum power
that the processor can dissipate.
2.
This table shows the maximum TDP for a given frequency range. Individual processors may have a lower TDP. Therefore, the max-
imum T will vary depending on the TDP of the individual processor. Refer to thermal profile figure and associated table for the
C
allowed combinations of power and T .
C
