TLE9263QX
Voltage Regulator 1
6.3
Electrical Characteristics
Table 9
Electrical Characteristics
VS = 5.5 V to 28 V; Tj = -40 °C to +150 °C; all voltages with respect to ground, positive current flowing into pin
(unless otherwise specified)
Parameter
Symbol
Values
Unit Note / Test Condition Number
Min. Typ. Max.
Output Voltage including line
and Load regulation
VCC1,out1
4.9
5.0
5.1
V
1)SBC Normal Mode;
10µA < IVCC1 < 250mA
6V < VS < 28V
P_6.3.1
Output Voltage including line
and Load regulation
VCC1,out2
VCC1,out3
4.9
5.0
–
5.1
V
V
1)SBC Normal Mode;
10µA < IVCC1 < 150mA
1)2)SBC Normal Mode; P_6.3.12
20mA < IVCC1 < 90mA
8V < VS < 18V
P_6.3.7
Output Voltage including line
and Load regulation
4.97
5.07
25°C < Tj < 125°C
Output Voltage including line
and Load regulation
VCC1,out41 4.9
VCC1,out42 4.9
5.05 5.2
V
SBC Stop Mode;
1mA < IVCC1 < IVCC1,Ipeak
P_6.3.2
P_6.3.20
P_6.3.3
P_6.3.4
P_6.3.13
Output Voltage including line
and Load regulation
5.05 5.25
V
SBC Stop Mode;
10µA < IVCC1 < 1mA
Output Drop
VCC1,d1
VCC1,d2
–
–
–
–
500
500
3.5
mV
mV
mA
I
VCC1 = 50mA
VS=3V
IVCC1 = 150mA
Output Drop
–
VS=5V
2) ICC1 rising;
VS = 13.5V
-40°C < Tj < 150°C;
I_PEAK_TH = ‘0’
VCC1 Active Peak Threshold 1 IVCC1,Ipeak1,r
(Transition threshold between
low-power and high-power
mode regulator)
1.9
VCC1 Active Peak Threshold 1 IVCC1,Ipeak1,f 0.5
(Transition threshold between
high-power and low-power
1.3
4.3
3.4
–
–
mA
mA
mA
2) ICC1 falling;
VS = 13.5V
-40°C < Tj < 150°C;
I_PEAK_TH = ‘0’
2) ICC1 rising;
VS = 13.5V
-40°C < Tj < 150°C;
I_PEAK_TH = ‘1’
2) ICC1 falling;
VS = 13.5V
-40°C < Tj < 150°C;
I_PEAK_TH = ‘1’
P_6.3.17
P_6.3.18
P_6.3.19
P_6.3.6
mode regulator)
VCC1 Active Peak Threshold 2 IVCC1,Ipeak2,r
(Transition threshold between
low-power and high-power
mode regulator)
–
7.0
–
VCC1 Active Peak Threshold 2 IVCC1,Ipeak2,f 1.7
(Transition threshold between
high-power and low-power
mode regulator)
Over Current Limitation
IVCC1,lim
250
12002) mA
current flowing out of
pin, VCC1 = 0V
1) In SBC Stop Mode, the specified output voltage tolerance applies when IVCC1 has exceeded the selected active peak
threshold (IVCC1,Ipeak1,r or IVCC1,Ipeak2,r) but with increased current consumption.
2) Not subject to production test, specified by design.
Data Sheet
40
Rev. 1.1, 2014-09-26
