TLE 6244X
1.12 Notes for the Diagnostics
- SCB entry in DIA_REGx see diagrams in chapter 1.6.4.
- In case of overvoltage at pin VDD (VDD > 5,5V) the diagnostic information can be wrong. In
that case, the diagnostic information has to be cleared with the DEL_DIA instruction.
- The filtering time restarts when the output voltage passes the diagnostic threshold for
short to ground (SCG).
- Diagram of the typical diagnostic current:
I
OUTPUT
580 µA
A
A
3.5V
14V
0V
5V
2.7V
U
OUT
B
-130 µA
A
A
Short to GND
Open load
o. k.
C
D
A: Diagnostic current (see 3.11.3)
B: Bias Voltage Open Load (see3.11.2)
C: Short to GND Threshold (see 3.11.1.2)
D: Open load Threshold (see 3.11.1.1)
Final Data Sheet
38
V4.2, 2003-08-29
