TC39x BC/BD-Step
HistoryChanges from Version 1.1 to Version 1.2
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
Changed GTM input channel at Port 20 in “LFBGA-292 ADAS Package Variant” tables
Changed function description for QSPI at Port 20 in “LFBGA-292 ADAS Package Variant” tables
Added function description for DMU at Port 21 in “LFBGA-292 ADAS Package Variant” tables
Changed function descriptions for QSPI at Port 22 in “LFBGA-292 ADAS Package Variant” tables
Changed function descriptions for HSPDM at Port 22 in “LFBGA-292 ADAS Package Variant” tables
Changed function description for CCU at Port 23 in “LFBGA-292 ADAS Package Variant” tables
Changed GTM input channel at Port 23 in “LFBGA-292 ADAS Package Variant” tables
Changed GTM input channel at Port 23 in “LFBGA-292 ADAS Package Variant” tables
Changed symbols at balls Y17 and W17 at Port 32 in “LFBGA-292 ADAS Package Variant” tables
Changed function description for CCU at Port 32 in “LFBGA-292 ADAS Package Variant” tables
Changed function description for PMS at Port 32 in “LFBGA-292 ADAS Package Variant” tables
Changed function description for EDSADC at Port 33 in “LFBGA-292 ADAS Package Variant” tables
Changed function description for PSI5S at Port 33 in “LFBGA-292 ADAS Package Variant” tables
Changed function description for QSPI at Port 33 in “LFBGA-292 ADAS Package Variant” tables
Changed function description for QSPI at Port 34 in “LFBGA-292 ADAS Package Variant” tables
Changed all function descriptions at Port 50 in “LFBGA-292 ADAS Package Variant” tables
Changed all function descriptions at Port 51 in “LFBGA-292 ADAS Package Variant” tables
Added notes to table “System I/O” for “LFBGA-292 ADAS Package Variant”
Changed symbols, Ctrl., buffer types and functions for several balls in “System I/O” table for “LFBGA-292
ADAS Package Variant”
–
Changed symbols and function descriptions for different balls in “Supply” table for “LFBGA-292 ADAS
Package Variant”
–
–
–
–
Changed sub-chapter title from “Pin Position Definition” to “Sequence of Pads in Pad Frame”
Changed comments for pad name VDDP3 (51, 52) in Pad List of “Sequence of Pads in Pad Frame”
Changed pad type for pad names P11.5, P11.7, P11.9, P11.8, P11.10, P11.11, P11.12 in Pad List of
“Sequence of Pads in Pad Frame”
–
–
Changed comment for pad 206 in Pad List of “Sequence of Pads in Pad Frame”
Changed comment and pad type for pad name AGBTCLKN in Pad List of “Sequence of Pads in Pad
Frame”
–
–
–
–
–
–
–
–
–
–
Changed comment and pad type for pad name AGBTCLKP in Pad List of “Sequence of Pads in Pad Frame”
Changed comment and pad type for pad name AGBTTXN in Pad List of “Sequence of Pads in Pad Frame”
Changed comment and pad type for pad name AGBTTXP in Pad List of “Sequence of Pads in Pad Frame”
Changed comment for pad name AGBTERR in Pad List of “Sequence of Pads in Pad Frame”
Changed pad names for pads 371, 372, 374, 375 in Pad List of “Sequence of Pads in Pad Frame”
Changed comment for pad 381 in Pad List of “Sequence of Pads in Pad Frame”
Changed pad names for pads 505, 506, 509, 510 in Pad List of “Sequence of Pads in Pad Frame”
Changed pad types and comments for pads 507, 508 in Pad List of “Sequence of Pads in Pad Frame”
Changed comment for pad 562 in Pad List of “Sequence of Pads in Pad Frame”
Changed comment parts for table Pad List of “Sequence of Pads in Pad Frame”
•
Changes in chapter “Electrical Specification”
Data Sheet
545
V 1.2, 2021-03
OPEN MARKET VERSION
