TC39x BC/BD-Step
HistoryChanges from Version 1.1 to Version 1.2
–
–
–
–
–
–
–
–
–
–
–
–
Changed function description for HSPDM at Port 22 in “LFBGA-516 Package Variant”
Changed function description for CCU at Port 23 in “LFBGA-516 Package Variant” tables
Changed function description for GTM at Port 23 in “LFBGA-516 Package Variant” tables
Changed function description for PMS at Port 32 in “LFBGA-516 Package Variant” tables
Changed function description for CCU at Port 32 in “LFBGA-516 Package Variant” tables
Changed function description for EDSADC at Port 33 in “LFBGA-516 Package Variant” tables
Changed function description for PSI5S at Port 33 in “LFBGA-516 Package Variant” tables
Changed wording for QSPI function at Port 33 in “LFBGA-516 Package Variant” tables
Changed wording for QSPI function at Port 34 in “LFBGA-516 Package Variant” tables
Changed function descriptions for EDSADC in table “Analog Inputs” in “LFBGA-516 Package Variant”
Added notes to table “System I/O” for “LFBGA-516 Package Variant”
Changed symbols, buffer types and functions for several balls in “System I/O” table for “LFBGA-516
Package Variant”
–
Changed symbols and function descriptions for different balls in “Supply” table for “LFBGA-516 Package
Variant”
–
–
–
–
–
–
–
–
–
–
–
–
Changed function descriptions for EDSADC at Port 00 in “LFBGA-292 Package Variant” tables
Changed function descriptions for EDSADC at Port 01 in “LFBGA-292 Package Variant” tables
Changed function descriptions for EDSADC at Port 02 in “LFBGA-292 Package Variant” tables
Changed function descriptions for PSI5S at Port 02 in “LFBGA-292 Package Variant” tables
Changed function descriptions for I2C at Port 02 in “LFBGA-292 Package Variant” tables
Changed wording for QSPI function at Port 02 in “LFBGA-292 Package Variant” tables
Changed GTM input channel at Port 02 in “LFBGA-292 Package Variant” tables
Changed wording for QSPI function at Port 10 in “LFBGA-292 Package Variant” tables
Deleted function description for SCU at Port 10 in “LFBGA-292 Package Variant” tables
Added function description for PMS at Port 10 in “LFBGA-292 Package Variant” tables
Changed Buffer Type description for P11.5, P11.7, P11.8, P11.9, P11.10, P11.11, P11.12 at Port 11 in
“LFBGA-292 Package Variant” tables
–
–
–
–
–
–
–
–
–
–
–
–
–
–
Changed function description for CCU at Port 11 in “LFBGA-292 Package Variant” tables
Changed function descriptions for I2C at Port 11 in “LFBGA-292 Package Variant” tables
Changed GTM input channel at Port 11 in “LFBGA-292 Package Variant” tables
Changed function description for GETH at Port 12 in “LFBGA-292 Package Variant” tables
Changed function description for I2C at Port 13 in “LFBGA-292 Package Variant” tables
Deleted function descriptions for SCU at Port 14 in “LFBGA-292 Package Variant” tables
Added function descriptions for PMS at Port 14 in “LFBGA-292 Package Variant” tables
Changed wording for QSPI function at Port 14 in “LFBGA-292 Package Variant” tables
Changed function description for I2C at Port 15 in “LFBGA-292 Package Variant” tables
Changed wording for QSPI function at Port 15 in “LFBGA-292 Package Variant” tables
Changed function description for CCU at Port 20 in “LFBGA-292 Package Variant” tables
Changed GTM input channel at Port 20 in “LFBGA-292 Package Variant” tables
Changed wording for QSPI function at Port 20 in “LFBGA-292 Package Variant” tables
Added function description for DMU at Port 21 in “LFBGA-292 Package Variant” tables
