TC39x BC/BD-Step
HistoryChanges from Version 0.7 to Version 1.0
–
Added footnote 5) for IEXTFLEX
•
•
•
•
Changes in table 'Module Current Consumption'
–
–
–
–
Changed value and condition of parameter IEXTLVDS
Added footnote 3) to IEXTLVDS
Added footnote 5) to IDDM
Changed footnote 8) for ISCRIDLE
Changes in table 'Module Core Current Consumption'
–
–
–
–
Changed footnote 1) for IDDHSM
Changed footnote for IDDSPU2
Removed parameter IDDSPU1
Removed parameter IDDSPULJ1
Changes in chapter “Supply Ramp-up and Ramp-down Behavior”
–
–
–
–
Changed Figure and textual description for “Single supply mode (a)”
Changed Figure and textual description for “Single supply mode (e)”
Changed Figure and textual description for “Single supply mode (d)”
Changed Figure and textual description for “Single supply mode (h)”
Changes in table 'Reset'
–
–
Added parameter tWARMRSTSEQ
Shift typ limit to max limits for mode0 and mode1 and removed typ limits for parameter tSCR
•
•
Changes in table 'EVR33 LDO'
Added footnote 7) for dVOUT / dIOUT
Changes in table 'Supply Monitors'
–
–
–
–
–
–
–
Changed condition of parameter VRST33
Changed condition of parameter VRSTC
Changed values of parameter VEXTMON
Changed footnote 2) for VEXTPRIUV, VDDP3PRIUV, VDDPRIUV,
Changed footnote 3) for VDDP3PRIUV, VDDPRIUV,
Added footnote 5) for VEXTMON, VDDP3MON, VDDMON
•
Changes in table 'EVRC SMPS External Components'
Add values of parameter 'LDC' for condition 0.8MHz
–
•
•
Changed chapter naming from 'Phase Locked Loop (PLL)' to 'System Phase Locked Loop (SYS_PLL)'
Changes in table 'PLL System'
–
Removed parameter values of 'fMV'
Changes in table 'QSPI Master Mode Timing'
Added footnote 1) for all parameters
Changes in table 'MSC LVDS clock/data'
Added footnote 3) for all parameters
Changes in chapter 'HSCT Parameters'
Added table for “HSCT”
•
•
•
–
–
–
•
•
Add chapter FSP Parameter
Changes in table 'Flash'
–
Changed description of parameter of NDFD
Data Sheet
540
V 1.2, 2021-03
OPEN MARKET VERSION
