TC39x BC/BD-Step
HistoryChanges from Version 0.7 to Version 1.0
–
–
Changed values and notes of parameter IOZ2
Added parameter and conditions for IOZ2
•
•
Changes in table 'LVDS - IEEE standard LVDS general purpose link (GPL)' of LVDS Pads
–
–
–
Added footnote 1) for tRISE20
Added footnote 2) for tFALL20
Changed order of footnotes
Changes in table 'VADC 5V'
–
–
–
–
Added values and conditions of parameter VAREF
Changed values and conditions of VAREF
Added footnote 1) for VAREF
Changed order of footnotes
•
•
Changes in table 'DSADC 5V'
–
–
Changed value of parameter VAREF
Added value and condition of parameter IREF
Changes in table 'OSC_XTAL'
–
–
–
–
Added parameter for DCX1
Added parameter for JABSX1
Added parameter for SRXTAL1
Added footnote 3) for DCX1, JABSX1, SRXTAL1
•
Changes in table 'Back-up Clock'
–
–
Changed value of parameter fSB
Changed footnote 1) for fBACKT
•
•
•
Changes in table 'DTS PMS'
Added parameter conditions for TNL
Changes in table 'DTS Core'
Added parameter conditions for TNL
Changes in description of chapter 'Power Supply Current'
–
–
–
–
–
–
Changed information of real power pattern
Added peripherals information
Added max power pattern
Added ADAS power pattern
•
Changes in table 'Current Consumption'
–
–
–
–
–
–
–
–
–
–
Added value and conditions for parameter IDDRAIL
Added parameter for parameter PDSR
Added conditions for parameter PDSR
Changed value for parameter ISLEEP
Addded parameter for IDDP3RAIL
Remove footnote 1) for IDDP3RAIL
Changed footnote 1) for IDDPORST , IEXTFLEX , IEVRSB , ISLEEP
Mapped footnote 2) to all values of IDD3RAIL
Changed footnote 3) for IEXTFLEX
Changed order of footnotes
Data Sheet
539
V 1.2, 2021-03
OPEN MARKET VERSION
