TC39x BC/BD-Step
HistoryChanges from Version 0.7 to Version 1.0
•
•
Changes in table "Operating Conditions"
–
–
Added footnote 1) for "VDD"
Changed order of footnotes
Changes in table 'PORST Pad'
–
–
–
Added values and notes for parameter VIH
Added values and notes for parameter VIL
Added footnote 2) for IPDL
•
•
•
Changes in table 'Fast 5V GPIO' of Standard Pads
–
–
–
–
Removed values and conditions of parameter IOZ
Changed footnote 2) for tRF
Added footnote 4) for IPUH
Added footnote 5) for IPDL
Changes in table 'Fast 3.3V GPIO' of Standard Pads
–
–
–
–
Combined equal values of IOZ in single line
Changed footnote 2) for tRF
Added footnote 4) for IPUH
Added footnote 5) for IPDL
Changes in table 'Slow 5V GPIO' of Standard Pads
–
–
–
–
–
Removed values and conditions of parameter IOZ
Combined equal values of IOZ in single line
Changed footnote 2) for tRF
Added footnote 4) for IPUH
Added footnote 5) for IPDL
•
Changes in table 'Slow 3.3V GPIO' of Standard Pads
–
–
–
–
–
Removed values and conditions of parameter IOZ
Combined equal values of IOZ in single line
Changed footnote 2) for tRF
Added footnote 4) for IPUH
Added footnote 5) for IPDL
•
•
•
Changes in table 'RFast 5V GPIO' of Standard Pads
–
–
–
Changed footnote 2) for tRF
Added footnote 4) for IPUH
Added footnote 5) for IPDL
Changes in table 'RFast 3.3V pad' of Standard Pads
–
–
–
Changed footnote 2) for tRF
Added footnote 4) for IPUH
Added footnote 5) for IPDL
Changes in table 'Class S 5V' of Standard Pads
–
–
Added footnote 2) for IPUH
Added footnote 3) for IPDL
•
•
Add table 'Class S 3.3V'
Changes in table 'ADC Reference Pads' of Standard Pads
Data Sheet
538
V 1.2, 2021-03
OPEN MARKET VERSION
