TC39x BC/BD-Step
HistoryChanges from Version 0.7 to Version 1.0
–
Changes in LFBGA-292 Package Variant 'Analog Inputs' table; Ball W5, U5
•
Changes in chapter 'TC39x Pin Definition and Functions' for package variant LFBGA-292 ADAS
–
–
–
–
Changes in LFBGA-292 ADAS Package Variant 'Port 00 Functions' table; P00.0, P00.1, P00.2, P00.3,
P00.4, P00.5, P00.11, P00.12
Changes in LFBGA-292 ADAS Package Variant 'Port 02 Functions' table; P02.0, P02.1, P02.2, P02.3,
P02.4, P02.5, P02.8
Changes in LFBGA-292 ADAS Package Variant 'Port 10 Functions' table; P10.2, P10.3, P10.5, P10.6,
P10.7, P10.8
Changes in LFBGA-292 ADAS Package Variant 'Port 11 Functions' table; P11.0, P11.1, P11.4, P11.5,
P11.7, P11.8, P11.10, P11.12, P11.13, P11.14
–
–
Changes in LFBGA-292 ADAS Package Variant 'Port 12 Functions' table; P12.0, P12.1
Changes in LFBGA-292 ADAS Package Variant 'Port 14 Functions' table; P14.0, P14.1, P14.6, P14.7,
P14.8, P14.9, P14.10
–
–
–
–
–
–
–
Changes in LFBGA-292 ADAS Package Variant 'Port 15 Functions' table; P15.0, P15.1, P15.2, P15.3,
P15.4, P15.5
Changes in LFBGA-292 ADAS Package Variant 'Port 20 Functions' table; P20.0, P20.3, P20.6, P20.7,
P20.8, P20.9, P20.10
Changes in LFBGA-292 ADAS Package Variant 'Port 21 Functions' table; P21.0, P21.1, P21.2, P21.3,
P21.4, P21.5
Changes in LFBGA-292 ADAS Package Variant 'Port 22 Functions' table; P22.2, P22.3, P22.4, P22.5,
P22.6, P22.7, P22.8, P22.9, P22.10, P22.11
Changes in LFBGA-292 ADAS Package Variant 'Port 23 Functions' table; P23.0, P23.1, P23.2, P23.3,
P23.5, P23.6, P23.7
Changes in LFBGA-292 ADAS Package Variant 'Port 32 Functions' table; P32.2, P32.3, P32.4, P32.5,
P32.6, P32.7
Changes in LFBGA-292 ADAS Package Variant 'Port 33 Functions' table; P33.0, P33.1, P33.2, P33.3,
P33.4, P33.5, P33.7, P33.8, P33.9, P33.10, P33.12, P33.13
–
–
Changes in LFBGA-292 ADAS Package Variant 'Port 34 Functions' table; P34.1, P34.2
Changes in LFBGA-292 Package Variant 'Analog Inputs' table; Ball W5, U5
•
•
Changes in chapter 'Pin Position Definition'
Changes in table “Pad List”, Number 206
Changed description in chapter 'Legend'
–
–
–
Column “Buffer Type”: PU2
add link to Spirit file
•
•
•
Changes in chapter “Electrical Specification”
Changed wording in sub-chapter “Parameter Interpretation”
Changes in table 'Absolute Maximum Ratings'
–
–
Added footnote 2) for VDD
Changed order of footnotes
•
Changes in table "Overload Parameters"
–
–
–
–
Changed table numbers in description
Changed parameter condition of "KOVAN"
Changed parameter condition of "KOVAP"
Added footnote 2) for “KOVAN” and "KOVAP"
Data Sheet
537
V 1.2, 2021-03
OPEN MARKET VERSION
