TC39x BC/BD-Step
HistoryChanges from Version 0.7 to Version 1.0
•
•
•
Changes in table "Back-up Clock"
Footnote change in Parameter "fBACKT"
Changes in table "DTS Core"
New Parameter "dT" added
Changes in table "VADC 5V"
–
–
–
–
–
–
–
–
–
–
–
Changed preamble
Change condition of Parameter "RPDD"
Change condition of Parameter "VDDK"
Change condition of Parameter "fADCI"
Change condition of Parameter "tS"
Change condition of Parameter "tSCAL"
New Parameter "VDDK" added
New Parameter "dVDDK" added
Footnote added to Parameter "QCONV"
4.3
Changes from Version 0.7 to Version 1.0
•
•
Changes in table “Platform Feature Overview”
Removed feature for “ASIL”
Changes in chapter “Pin Definition and Functions”
–
–
–
–
–
–
–
Changed naming from “BGA516” to “LFBGA-516”
Changed figure for “LFBGA-516”
Changed naming from “BGA292” to “LFBGA-292”
Changed figure for “LFBGA-292”
Changed naming from “BGA292 ADAS feature set” to “LFBGA-292 ADAS feature set”
Changed figure for “LFBGA-292 ADAS feature set”
•
Changes in chapter 'TC39x Pin Definition and Functions' for package variant LFBGA-516
–
–
–
–
–
Changes in LFBGA-516 Package Variant 'Port 00 Functions' table; P00.0, P00.1, P00.2, P00.3, P00.4,
P00.5, P00.11, P00.12
Changes in LFBGA-516 Package Variant 'Port 01 Functions' table; P01.0, P01.2, P01.3, P01.4, P01.8,
P01.13
Changes in LFBGA-516 Package Variant 'Port 02 Functions' table; P02.0, P02.1, P02.2, P02.3, P02.4,
P02.5, P02.8, P02.9, P02.10, P02.13, P02.14
Changes in LFBGA-516 Package Variant 'Port 10 Functions' table; P10.2, P10.3, P10.5, P10.6, P10.7,
P10.8
Changes in LFBGA-516 Package Variant 'Port 11 Functions' table; P11.0, P11.1, P11.4, P11.5, P11.7,
P11.8, P11.10, P11.12, P11.13, P11.14
–
–
Changes in LFBGA-516 Package Variant 'Port 12 Functions' table; P12.0, P12.1
Changes in LFBGA-516 Package Variant 'Port 13 Functions' table; P13.0, P13.1, P13.2, P13.4, P13.5,
P13.9, P13.12
–
Changes in LFBGA-516 Package Variant 'Port 14 Functions' table; P14.0, P14.1, P14.6, P14.7, P14.8,
P14.9, P14.10, P14.13, P14.14, P14.15
Data Sheet
535
V 1.2, 2021-03
