TC39x BC/BD-Step
HistoryChanges from Version 0.4 to Version 0.6
–
–
–
–
Change note of HYS from '0.1 * VEXT/FLEX V' to '0.09 * VEXT/FLEX V'
Change min value of HYS from 0.09 * VEXT/FLEX V to 0.075 * VEXT/FLEX V
Change note of IPDL from 'VIL; AL or TTL' to 'VIL; AL'
Change note of IOZ from 'TJ ≤ 150°C; PDD option available, or AltRef option available and EDSADC
channel connected or AN70 or AN71' to 'TJ ≤ 150°C; PDD option available, or AltRef option available and
EDSADC channel connected, or two EDSADC channels connected'
•
Changes in table 'RFast 3.3V pad' of Standard Pads
–
–
–
–
–
–
–
–
–
–
–
Change note of HYS from '0.065 * VEXT/FLEX V' to '0.055 * VEXT/FLEX V'
Change note of HYS from '0.1 * VEXT/FLEX V' to '0.09 * VEXT/FLEX V'
Change note of HYS from '0.07 * VEXT/FLEX V' to '0.055 * VEXT/FLEX V'
Change min value of RDSON from 140 Ohm to 125 Ohm
Change note of RDSON from '200 Ohm' to '225 Ohm'
Change note of RDSON from '300 Ohm' to '320 Ohm'
Change min value of RDSON from 35 Ohm to 31 Ohm
Change typ value of RDSON from 50 Ohm to 55 Ohm
Change max value of RDSON from 77 Ohm to 80 Ohm
Change min value of RDSON from 10 Ohm to 8 Ohm
Change note of tRF from 'CL = 25pF; driver = strong sharp edge' to 'CL = 25pF; driver = strong sharp edge;
from 0.2 * VEXT/FLEX to 0.8 * VEXT/FLEX
'
–
–
–
–
–
–
–
–
–
Change min value of tRF from 2 ns to 1.6 ns
Change min value of tRF from 4+0.57*CL ns to 2+0.57*CL ns
Change note of tRF from '0.75+0.15*CL ns' to '2.5+0.21*CL ns'
Change max value of tRF from 1.5+0.38*CL ns to 8+0.4*CL ns
Change note of tRF from '7+1.1*CL ns' to '10+1.25*CL ns'
Change min value of IPUH from |19| µA to |17| µA
Change note of IPUH from '|9| µA' to '|11| µA'
Change note of IPDL from '|18| µA' to '|15| µA'
Change note of tRF from 'CL = 25pF; driver = strong sharp edge' to 'CL = 25pF; driver = strong sharp edge;
from 0.2 * VEXT/FLEX to 0.8 * VEXT/FLEX
'
–
Change note of fOUTD from '' to 'medium driver'
•
Changes in table 'RFast 5V GPIO' of Standard Pads
–
–
–
–
–
–
–
–
–
–
Change min value of HYS from 0.1 * VEXT/FLEX V to 0.09 * VEXT/FLEX V
Change note of HYS from '0.09 * VEXT/FLEX V' to '0.075 * VEXT/FLEX V'
Change min value of RDSON from 140 Ohm to 125 Ohm
Change note of RDSON from '260 Ohm' to '320 Ohm'
Change note of RDSON from '200 Ohm' to '225 Ohm'
Change note of RDSON from '35 Ohm' to '31 Ohm'
Change max value of RDSON from 65 Ohm to 80 Ohm
Change note of RDSON from '50 Ohm' to '55 Ohm'
Change min value of tRF from 2.5+0.18*CL ns to 1.0+0.18*CL ns
Change note of tRF from ''CL = 25pF; driver = strong sharp edge'' to ''CL = 25pF; driver = strong sharp edge;
from 0.2 * VEXT/FLEX to 0.8 * VEXT/FLEX''
–
Change note of tRF from '2.8 ns' to '3.2 ns'
Data Sheet
523
V 1.2, 2021-03
