TC39x BC/BD-Step
Pin Definition and Functions: Sequence of Pads in Pad Frame
Table 2-63 Pad List (cont’d)
Number
Pad Name
Pad Type
X
Y
Comment
294
AN26/P40.2
S / HighZ /
VDDM
9860940
9189396
Analog Input 26
295
296
297
298
299
300
301
302
303
304
305
AN25/P40.1
AN24/P40.0
AN23
S / HighZ /
VDDM
9813942
9766944
9719946
9672948
9625950
9578952
9531954
9484956
9437958
9390960
9343962
9042426
9189396
9042426
9189396
9042426
9189396
9042426
9189396
9042426
9189396
9042426
Analog Input 25
Analog Input 24
Analog Input 23
Analog Input 22
Analog Input 21
Analog Input 20
Analog Input 19
Analog Input 18
Analog Input 17
Analog Input 16
Analog Input 15
S / HighZ /
VDDM
D / HighZ /
VDDM
AN22
D / HighZ /
VDDM
AN21
D / HighZ /
VDDM
AN20
D / HighZ /
VDDM
AN19/P40.12 S / HighZ /
VDDM
AN18/P40.11 S / HighZ /
VDDM
AN17/P40.10 S / HighZ /
VDDM
AN16
D / HighZ /
VDDM
AN15
D / HighZ /
VDDM
306
307
308
309
310
VAGND1
VAGND0
VAREF1
VAREF0
AN14
Vx
Vx
Vx
Vx
9296964
9249966
9202968
9155970
9108972
9189396
9042426
9189396
9042426
9189396
Supply Voltage
Supply Voltage
Supply Voltage
Supply Voltage
Analog Input 14
D / HighZ /
VDDM
311
312
313
VDDM
VSSM
AN13
Vx
Vx
9061974
9014976
8967978
9042426
9189396
9042426
Supply Voltage
Supply Voltage
Analog Input 13
D / HighZ /
VDDM
314
315
316
VSSM
VDDM
AN12
Vx
Vx
8920980
8873982
8826984
9189396
9042426
9189396
Supply Voltage
Supply Voltage
Analog Input 12
D / HighZ /
VDDM
317
318
AN11
AN10
D / HighZ /
VDDM
8779986
8732988
9042426
9189396
Analog Input 11
Analog Input 10
D / HighZ /
VDDM
Data Sheet
389
V 1.2, 2021-03
