TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-292 Package Variant Pin Configuration
Table 2-27 Port 02 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
F4
P02.11
I
SLOW /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 4 of TIM module 4
Mux input channel 5 of TIM module 3
Mux input channel 7 of TIM module 0
Receive input channel 22
Analog input channel 15, group 9
General-purpose output
GTM muxed output
GTM_TIM4_IN4_3
GTM_TIM3_IN5_12
GTM_TIM0_IN7_7
SENT_SENT22B
EVADC_G9CH15
AI
P02.11
O0
O1
O2
O3
O4
O5
O6
O7
GTM_TOUT118
—
Reserved
ASCLIN8_ASLSO
Slave select signal output
Reserved
—
—
—
—
Reserved
Reserved
Reserved
Table 2-28 Port 10 Functions
Ball
Symbol
Ctrl. Buffer
Type
Function
A7
P10.0
I
SLOW /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 0 of TIM module 4
Mux input channel 4 of TIM module 1
Mux input channel 4 of TIM module 0
Count direction control input of core timer T6
Receive input
GTM_TIM4_IN0_12
GTM_TIM1_IN4_2
GTM_TIM0_IN4_2
GPT120_T6EUDB
ASCLIN11_ARXA
GETH_RXERC
GTM_DTMA5_2
P10.0
Receive Error MII
CDTM5_DTM4
O0
O1
O2
O3
O4
O5
O6
O7
General-purpose output
GTM muxed output
GTM_TOUT102
ASCLIN11_ATX
QSPI1_SLSO10
—
Transmit output
Master slave select output
Reserved
EVADC_FC6BFLOUT
—
Boundary flag output, FC channel 6
Reserved
—
Reserved
