DF8MR12W1M1HF_B67
™
EasyPACK module
7 NTC-Thermistor
Table 13
Characteristic values
Symbol Note or test condition
Parameter
Values
Typ.
0.95
0.1
Unit
Min.
Max.
Forward voltage
Reverse current
VF
Ir
IF = 30 A
Tvj = 150 °C
V
Tvj = 150 °C, VR = 1200 V
per diode
mA
K/W
Thermal resistance,
junction to heat sink
RthJH
1.16
Temperature under
switching conditions
Tvj, op
-40
150
°C
7
NTC-Thermistor
Table 14
Characteristic values
Symbol Note or test condition
Parameter
Values
Typ.
5
Unit
Min.
Max.
Rated resistance
Deviation of R100
Power dissipation
B-value
R25
ΔR/R
P25
TNTC = 25 °C
kΩ
%
TNTC = 100 °C, R100 = 493 Ω
TNTC = 25 °C
-5
5
20
mW
K
B25/50 R2 = R25 exp[B25/50(1/T2-1/(298,15 K))]
B25/80 R2 = R25 exp[B25/80(1/T2-1/(298,15 K))]
B25/100 R2 = R25 exp[B25/100(1/T2-1/(298,15 K))]
3375
3411
3433
B-value
K
B-value
K
Note:
Specification according to the valid application note.
Datasheet
8
Revision 0.10
2022-11-21
