AIROC™ Bluetooth® system on chip for automotive applications
Acronyms
15
Acronyms
Table 34
Term
ACL
ADC
AFH
Acronyms used in this document
Description
asynchronous connection-less
analog-to-digital converter
adaptive frequency hopping
ARM7TDMI-S Acorn RISC Machine 7 Thumb instruction, Debugger, Multiplier, Ice, Synthesizable
BBC
BDR
BLE
BR
Bluetooth® Baseband Core
basic data rate
Bluetooth® low energy
basic data rate
CMOS
CRC
ECDSA
ED
complementary metal oxide semiconductor
cyclic redundancy check
elliptic curve digital signature algorithm
erroneous data
EDR
EIR
enhanced data rate
extended inquiry response
extended power down sleep
extended synchronous connection-oriented
encryption pause resume
forward error correction
floating point unit
ePDS
eSCO
EPR
FEC
FPU
GAP
GATT
GCI
generic access profile
generic attribute profile
global coexistence interface
Gaussian Frequency Shift Keying
general-purpose I/O
GFSK
GPIO
HCI
host control interface
HEC
HID
I2C
header error control
human-interface device
inter-integrated circuit
inter-IC sound bus
I2S
IF
intermediate frequency
Joint Test Action Group
logical link control and adaptation protocol
link control
JTAG
L2CAP
LC
LCU
LDO
LE
link control unit
low drop out
low energy
LED
light emitting diode
Datasheet
49
002-25826 Rev. *G
2022-09-24
