PROFET + 24V
BTT6200-4ESA
Application information
10
Application information
Note:
The following information is given as a hint for the implementation of the device only and shall not be
regarded as a description or warranty of a certain functionality, condition or quality of the device.
VBAT
Voltage Regulator
OUT
VS
GND
T1
Z
CVDD
CVS
VDD
VS
RDEN
I/O
DEN
OUT0
OUT1
COUT
Relay
I/O
I/O
RDSEL
DSEL0
DSEL1
86
85
30
87
RDSEL
COUT
RIN
RIN
RIN
RIN
I/O
I/O
I/O
I/O
IN0
IN1
IN2
IN3
Micro
controller
+
-
OUT2
OUT3
COUT
E.C.U.
OUT3
OUT4
COUT
RSENSE
IS
A/D
GND
LED
R5W
GND
CSENSE
D
Page-1
Figure 29
Application diagram with BTT6200-4ESA
Note:
This is a very simplified example of an application circuit. The function must be verified in the real
application.
Table 12
Bill of material
Reference
Value
Purpose
RIN
10 kΩ
Protection of the microcontroller during overvoltage, reverse polarity
Guarantee BTT6200-4ESA channels OFF during loss of ground
RDSEL
RDEN
10 kΩ
10 kΩ
Protection of the microcontroller during overvoltage, reverse polarity
Protection of the microcontroller during overvoltage, reverse polarity
Datasheet
47
Rev. 1.00
2019-03-09
