PROFET + 24V
BTT6200-4ESA
Input pins
Table 11
Electrical characteristics: Input pins (continued)
VS = 8 V to 36 V, TJ = -40°C to 150°C (unless otherwise specified).
Typical values are given at VS = 28V, TJ = 25°C
Parameter
Symbol
Values
Typ.
Unit Note or Test
Condition
Number
Min.
Max.
Input voltage hysteresis
VIN(HYS)
–
250
–
mV
27) See Chapter
9.5
P_8.4.3
Low level input current
High level input current
IIN(L)
IIN(H)
1
2
10
10
25
25
µA
µA
VIN = 0.8 V
P_8.4.4
P_8.4.5
VIN = 5.5 V
See Chapter 9.5
DEN Pin
Low level input voltage range
VDEN(L)
-0.3
2
–
0.8
6
V
–
P_8.4.6
P_8.4.7
P_8.4.8
P_8.4.9
P_8.4.10
High level input voltage range VDEN(H)
–
V
–
27)
Input voltage hysteresis
Low level input current
High level input current
DSEL Pins
VDEN(HYS)
IDEN(L)
–
250
10
10
–
mV
µA
µA
1
25
25
VDEN = 0.8 V
VDEN = 5.5 V
IDEN(H)
2
Low level input voltage range
VDSEL(L)
-0.3
2
–
0.8
6
V
–
P_8.4.11
P_8.4.12
P_8.4.13
P_8.4.14
P_8.4.15
High level input voltage range VDSEL(H)
–
V
–
27)
Input voltage hysteresis
Low level input current
High level input current
VDSEL(HYS)
IDSEL(L)
–
250
10
10
–
mV
µA
µA
1
25
25
VDSEL = 0.8 V
VDSEL = 5.5 V
IDSEL(H)
2
27
Not subject to production test, specified by design.
Datasheet
40
Rev. 1.00
2019-03-09
