BTS7012-2EPA
PROFET™ +2 12V
General Product Characteristics
4
General Product Characteristics
4.1
Absolute Maximum Ratings - General
Table 3
Absolute Maximum Ratings1)
TJ = -40 °C to +150 °C; all voltages with respect to ground, positive current flowing into pin
(unless otherwise specified)
Parameter
Symbol
Values
Typ.
Unit Note or
Test Condition
Number
Min.
Max.
Supply pins
Power Supply Voltage
Load Dump Voltage
VS
-0.3
–
–
–
28
35
V
V
–
P_4.1.0.1
P_4.1.0.3
VBAT(LD)
suppressed
Load Dump
acc. to
ISO16750-2
(2010).
Ri = 2 Ω
Supply Voltage for Short Circuit VBAT(SC)
Protection
0
–
–
–
24
16
V
V
Setup acc. to
AEC-Q100-012
P_4.1.0.25
P_4.1.0.5
Reverse Polarity Voltage
-VBAT(REV)
t ≤ 2 min
TA = +25 °C
Setup as
described in
Chapter 10
Current through GND Pin
IGND
-50
–
50
mA
RGND according P_4.1.0.9
to Chapter 10
Logic & control pins (Digital Input = DI)
DI = INn, DEN, DSEL
2)
Current through DI Pin
IDI
-1
-1
–
–
2
mA
mA
P_4.1.0.14
2)
Current through DI Pin
IDI(REV)
10
P_4.1.0.36
Reverse Battery Condition
t ≤ 2 min
IS pin
Voltage at IS Pin
Current through IS Pin
VIS
IIS
-1.5
-25
–
–
VS
V
IIS = 10 μA
P_4.1.0.16
P_4.1.0.18
IIS(SAT),M mA
–
AX
Temperatures
Junction Temperature
Storage Temperature
TJ
-40
-55
–
–
150
150
°C
°C
–
–
P_4.1.0.19
P_4.1.0.20
TSTG
Data Sheet
7
Rev. 1.10
2020-12-14
