HY2120
2-Cell Lithium-ion/Lithium Polymer Battery Packs Protection ICs
14.2.Tape & Reel Information---SOT-23-6 (Type 2)
Unit : mm.
14.2.1. Reel Dimensions
14.2.2. Carrier Tape Dimensions
.
Reel
Carrier Tape Dimensions
SYMBOLS
Spec.
Dimensions
A
W1
9.4
A0
B0
K0
P0
P1
P2
E
F
D0
W
178
3.17 3.23 1.37 4.00 4.00 2.00 1.75 3.50 1.55
8.00
Tolerance ±2.00 ±1.50 ±0.10 ±0.10 ±0.10 ±0.10 ±0.10 ±0.05 ±0.10 ±0.05 ±0.05 +0.30/-0.10
Note: 10 Sprocket hole pitch cumulative tolerance is ±0.20mm.
14.2.3. Pin1 direction
© 2009-2015 HYCON Technology Corp
www.hycontek.com
DS-HY2120-V15_EN
page21
