ꢀProduct Specifications
Current rating
Voltage rating
0.3A
Operating Temperature Range
Operating Humidity Range
Storage Temperature Range
Storage Humidity Range
-35 to 85ç (Note 1)
40 to 80%
-10 to 60ç(Note 2)
40 to 70%
Rating
50V AC
Item
Specification
Condition
1. Insulation Resistance
2. Withstanding voltage
3. Contact Resistance
4. Vibration
100V DC
150V AC/1 minute
100mA
Frequency: 10 to 55 Hz, single amplitude of 0.75 mm, 2 hours in each of the 3 directions.
96 hours at temperature of 40ç and humidity of 90% to 95%
(-55ç: 30 minutes 5 to 35ç: 10 minutes 85ç: 30 minutes 5 to 35ç: 10 minutes) 5 cycles
50 cycles
Reflow: At the recommended temperature profile
Manual soldering: 300ç for 3 seconds
500M ohms min.
No flashover or insulation breakdown.
60m ohms max.
No electrical discontinuity of 1µs or more
Contact resistance: 60m ohms max Insulation resistance:250M ohms min
Contact resistance: 60m ohms max:Insulation resistance: 500M ohms min
Contact resistance: 60m ohms
5.
Humidity (Steady state)
6. Temperature Cycle
7. Durability (Mating/un-mating)
8. Resistance to
No deformation of components affecting performance.
Soldering heat
Note 1: Includes temperature rise caused by current flow.
Note 2: The term "storage" refers to products stored for long period of time prior to mounting and use. Operating Temperature Range and
Humidity range covers non conducting condition of installed connectors in storage, shipment or during transportation.
ꢀMaterial
Product
Part
Material
Finish
White
Remarks
UL94V-0
Insulator
Contact
Polyamide
Receptacle
Phosphor copper
Phosphor copper
Polyamide
Gold plated (Note 1)
Tin-lead plated
White
---------------
---------------
Metal Fitting
Insulator
Contact
UL94V-0
Header
Phosphor copper
Phosphor copper
Gold plated (Note 2)
Tin-lead plated
---------------
---------------
Metal Fitting
Note1: DF17(0.3)-*DS-0.5V : Contact area: gold plating/lead area: flash gold plated
DF17(4.0)-*DS-0.5V : Contact area: gold plating/lead area: tin-lead plated
DF17(4.0)-*DP-0.5V : Contact area: gold plating/lead area: tin-lead plated
Note2: The header gold plated product:Contact area: gold plating/lead area: tin-lead plated
DF17(1.0H)-*DS-0.5V only: Contact area: gold plating/lead area: flash gold plated
BOrdering Information
Please determine the specific product. If needed, please select and orderproducts from the product No. as listed on catalog page
A322~A325.
Receptacle/Header
ꢀ
( )
( )
DF17 #
** - * DS - 0.5 V **
1
2
3
4
5
6
7
8
Series Name: DF17
Type
Number of Contacts
1
2
4
5
20,26,30,40,50,6,70,80contacts
Connector Type
Fitting
Boss
K
DS: Receptacle
DP: Header
DF17
K
∞
K
∞
DF17A
DF17B
DF17C
K
∞
∞
Contact Pitch: 0.5mm
6
7
Contact Type
V: Straight SMT
Packaging Type (50): Gold plated, embossed tape packaging
(51): Gold plated, tube packaging
3
8
Product height
The stacking height can be determined by adding the
figures in parentheses to receptacle and header.
A321
