HT95LXXX
SET [m]
Set data memory
Description
Operation
Each bit of the specified data memory is set to 1.
[m] ¬ FFH
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
¾
¾
¾
¾
SET [m]. i
Set bit of data memory
Description
Operation
Bit i of the specified data memory is set to 1.
[m].i ¬ 1
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
¾
¾
¾
¾
SIZ [m]
Skip if increment data memory is 0
Description
The contents of the specified data memory are incremented by 1. If the result is 0, the fol-
lowing instruction, fetched during the current instruction execution, is discarded and a
dummy cycle is replaced to get the proper instruction (2 cycles). Otherwise proceed with
the next instruction (1 cycle).
Operation
Skip if ([m]+1)=0, [m] ¬ ([m]+1)
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
¾
¾
¾
¾
SIZA [m]
Increment data memory and place result in ACC, skip if 0
Description
The contents of the specified data memory are incremented by 1. If the result is 0, the next
instruction is skipped and the result is stored in the accumulator. The data memory re-
mains unchanged. If the result is 0, the following instruction, fetched during the current in-
struction execution, is discarded and a dummy cycle is replaced to get the proper
instruction (2 cycles). Otherwise proceed with the next instruction (1 cycle).
Operation
Skip if ([m]+1)=0, ACC ¬ ([m]+1)
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
¾
¾
¾
¾
SNZ [m].i
Skip if bit i of the data memory is not 0
Description
If bit i of the specified data memory is not 0, the next instruction is skipped. If bit i of the data
memory is not 0, the following instruction, fetched during the current instruction execution,
is discarded and a dummy cycle is replaced to get the proper instruction (2 cycles). Other-
wise proceed with the next instruction (1 cycle).
Operation
Skip if [m].i¹0
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
¾
¾
¾
¾
Rev. 1.20
44
May 26, 2004
