Preliminary
HT48R06A-1
RLC [m]
Rotate data memory left through carry
Description
The contents of the specified data memory and the carry flag are rotated one
bit left. Bit 7 replaces the carry bit; the original carry flag is rotated into the
bit 0 position.
Operation
[m].(i+1) ¬ [m].i; [m].i:bit i of the data memory (i=0~6)
[m].0 ¬ C
C ¬ [m].7
Affected flag(s)
TC2 TC1 TO PD OV
Z
AC
C
¾
¾
¾
¾
¾
¾
¾
Ö
RLCA [m]
Rotate left through carry and place result in the accumulator
Description
Data in the specified data memory and the carry flag are rotated one bit left.
Bit 7 replaces the carry bit and the original carry flag is rotated into bit 0 po-
sition. The rotated result is stored in the accumulator but the contents of the
data memory remain unchanged.
Operation
ACC.(i+1) ¬ [m].i; [m].i:bit i of the data memory (i=0~6)
ACC.0 ¬ C
C ¬ [m].7
Affected flag(s)
TC2 TC1 TO PD OV
Z
AC
C
¾
¾
¾
¾
¾
¾
¾
Ö
RR [m]
Rotate data memory right
Description
The contents of the specified data memory are rotated one bit right with bit 0
rotated to bit 7.
Operation
[m].i ¬ [m].(i+1); [m].i:bit i of the data memory (i=0~6)
[m].7 ¬ [m].0
Affected flag(s)
TC2 TC1 TO PD OV
Z
AC
C
¾
¾
¾
¾
¾
¾
¾
¾
36
February 25, 2000
