HT46R64/HT46C64
XOR A,[m]
Logical XOR accumulator with data memory
Description
Data in the accumulator and the indicated data memory perform a bitwise logical Exclu-
sive_OR operation and the result is stored in the accumulator.
Operation
ACC ¬ ACC ²XOR² [m]
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
¾
Ö
¾
¾
XORM A,[m]
Logical XOR data memory with the accumulator
Description
Data in the indicated data memory and the accumulator perform a bitwise logical Exclu-
sive_OR operation. The result is stored in the data memory. The 0 flag is affected.
Operation
[m] ¬ ACC ²XOR² [m]
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
¾
Ö
¾
¾
XOR A,x
Logical XOR immediate data to the accumulator
Description
Data in the accumulator and the specified data perform a bitwise logical Exclusive_OR op-
eration. The result is stored in the accumulator. The 0 flag is affected.
Operation
ACC ¬ ACC ²XOR² x
Affected flag(s)
TO
PDF
OV
Z
AC
C
¾
¾
¾
Ö
¾
¾
Rev. 1.80
44
February 14, 2006
