Product Tape and Reel Specifications
Reel Dimensions
D
T
2
C
A
B
T
1
SOP 16N (150mil)
Symbol
Description
Dimensions in mm
330.0±1.0
A
B
Reel Outer Diameter
Reel Inner Diameter
Spindle Hole Diameter
Key Slit Width
100.0±1.5
+0.5/-0.2
13.0
C
D
2.0±0.5
+0.3/-0.2
16.8
T1
T2
Space Between Flange
Reel Thickness
22.2±0.2
SOP 20W, SOP 24W, SOP 28W (300mil)
Symbol
Description
Dimensions in mm
330.0±1.0
A
B
Reel Outer Diameter
Reel Inner Diameter
Spindle Hole Diameter
Key Slit Width
100.0±1.5
+0.5/-0.2
13.0
C
D
2.0±0.5
+0.3/-0.2
24.8
T1
T2
Space Between Flange
Reel Thickness
30.2±0.2
SSOP 20S (150mil), SSOP 24S (150mil), SSOP 28S (150mil)
Symbol
Description
Reel Outer Diameter
Dimensions in mm
330.0±1.0
A
B
Reel Inner Diameter
Spindle Hole Diameter
Key Slit Width
100.0±1.5
+0.5/-0.2
13.0
C
D
2.0±0.5
+0.3/-0.2
16.8
T1
T2
Space Between Flange
Reel Thickness
22.2±0.2
