HT46R064B/065B/066B
Package Information
Note that the package information provided here is for consultation purposes only. As this information may be updated at regu-
lar intervals users are reminded to consult the Holtek website (http://www.holtek.com.tw/english/literature/package.pdf) for
the latest version of the package information.
16-pin DIP (300mil) Outline Dimensions
A
A
9
8
1
6
9
8
1
6
B
B
1
1
H
H
C
D
C
D
G
G
E
E
I
I
F
F
Fig1. Full Lead Packages
Fig2. 1/2 Lead Packages
·
MS-001d (see fig1)
Dimensions in inch
Symbol
Min.
0.780
0.240
0.115
0.115
0.014
0.045
¾
Nom.
¾
Max.
0.880
0.280
0.195
0.150
0.022
0.070
¾
A
B
C
D
E
F
G
H
I
¾
¾
¾
¾
¾
0.100
0.300
¾
0.325
0.430
¾
¾
Dimensions in mm
Symbol
Min.
19.81
6.10
2.92
2.92
0.36
1.14
¾
Nom.
¾
Max.
22.35
7.11
4.95
3.81
0.56
1.78
¾
A
B
C
D
E
F
G
H
I
¾
¾
¾
¾
¾
2.54
7.62
¾
8.26
10.92
¾
¾
Rev. 1.10
79
October 23, 2012
