32-bit ARM Cortex™-M3 MCU
HT32F1251/51B/52/53
I/O Ports
▄
Up to 32 GPIOs
▄
Port A and Port B are mapped as 16 external interrupts (EXTI)
▄
Almost all I/O pins are 5 V-tolerant except for pins shared with analog inputs
There are up to 32 General Purpose I/O pins, (GPIO), named PA0 ~ PA15 and PB0 ~ PB15 for the
device to implement logic input/output functions. Each of the GPIO ports has related control and
configuration registers to satisfy the requirements of specific applications.
The GPIO ports are pin-shared with other alternative functions (AFs) to obtain maximum flexibility
on the package pins. The GPIO pins can be used as alternative functional pins by configuring the
corresponding registers regardless of the AF input or output pins.
The external interrupts on the GPIO pins of the device have related control and configuration
registers in the External Interrupt Control Unit (EXTI).
PWM Generation and Capture Timers
▄
Two 16-bit General-Purpose Timers (GPTM)
▄
Up to 4CHs PWM compare output or input capture for each GPTM
▄
External trigger input
The General-Purpose Timers, known as GPTM0 and GPTM1, consist of one 16-bit up/down-
counter, four 16-bit Capture/Compare Registers (CCRs), one 16-bit Counter-Reload Register (CRR)
and several control/status registers. They can be used for a variety of purposes including general
time, input signal pulse width measurement or output waveform generation such as single pulse
generation or PWM output. The GPTM supports an Encoder Interface using a decoder with two
inputs.
