HA17555 Series
Absolute Maximum Ratings (Ta = 25°C)
Item
Symbol
VCC
HA17555PS/FP
18
HA17555/F
18
Unit
V
Supply voltage
Discharge current
Output source current
Output sink current
Power dissipation*1
Operating temperature
Storage temperature
IT
200
200
mA
mA
mA
mW
°C
Isource
Isink
PT
200
200
200
200
600/385
–20 to +75
–55 to +125
600/385
–20 to +70
–55 to +125
Topr
Tstg
°C
Note: 1. For the HA17555/PS,
This value applies up to Ta = 50°C; at temperatures above this, 8.3mW/°C derating should be
applied.
For the HA17555F/FP,
This value applies up to Ta = 25°C; at temperatures above this, 3.85mW/°C derating should be
applied.
See notes on SOP Package Usage in Reliability section.
