assuredcommunications
®
RF-300M-V150
50-watt Multiband VehiculaR
aMpliFieR adapteR (Vaa)
(including an/pRc-117g(V)1(c))
A high-efficiency VAA for the
FAlcon III
®
Manpack radio in a
low-profile, compact package
The Falcon III
®
RF-300M-V150 is a 50-watt vehicular amplifier
adapter (Vaa) that includes the Falcon III an/PRc-117G(V)1(c)
manpack radio. Designed for long-range applications and increased
communications reliability, the RF-300M-V150 provides 50 watts from
30 to 450 MHz and 20 watts from 450 MHz to 2 GHz, supporting both
narrowband and wideband waveforms up to 5 MHz bandwidth.
The single-unit Vaa is extremely low-profile and can be deployed in
multiple configurations, including as a single unit, alongside a single
channel an/VRc-110, or in a dual-unit configuration mounted in the
Universal SIncGaRS Interface Module (USIM).
The Vaa features separate VHF, UHF, SaTcoM, and wideband antenna
ports with automatic port switching, providing the radio system with true
multimission capability. The operator only needs to select the required
preset on the radio to switch among ground, ground-to-air, SaTcoM,
and wideband networking communications.
other features provided by the RF-300M-V150 include: VHF (30 to 90
Mhz) and UHF (200 to 400 MHz) collocation filters, internal lna, VIc-1
and VIc-3 interface, wideband Pa control interface, and external power
output to power accessories such as a loudspeaker or battery charger.
The Vaa provides a mechanism to lock the manpack radio for
physical security.
