Specifications for the KGV-72
General
Interfaces
Programmable Type-1 encryption
for applications such as Force
Tracking
Front panel (single knob and
single LED) or remote control
via attached FBCB2 computer
Application
Control & Indicators
Certification
NSA Type-1
Power
Fill
28 volt nominal
DS-101
Both Red and Black key fill
Stores up to 125 TEKs and KEKs
Key Management
10/100 Ethernet; RS-422
(configurable to rates of 9.6, 19.2,
38.4, 57.6, 76.8, and 115.2 kbps)
Red Data
Physical
4.5 x 7.5 x 3 in. (11.4 x 19.1 x
7.6 cm), not including cable dress
Size
Black Data
Same rates as Red Data
3 lbs. (1.4 kg), not
including cables
Weight
Power
Mounting screws (4) and provisions
for a Series 200 lock included
Optional mounting available
for CCI equipment
Power Consumption
Voltage
6 watts (typical)
Mounting
28 volt vehicles nominal
Input Range 10–30 volts
Over/Under/Reverse protection per
MIL-STD-1275
Environmental
Durability
MIL–STD-810F
-40° to +70° C
Type ½ AA 14250C: NSN 6135-
01-525-9943
Hold-Up Battery
Operating & Storage
Temperature
6-pin fill compatible with
AN/CYZ10 and SKL
MS3114E14-19S
Red/Black connector (2)
Mounting holes (4)
MS3114E12-3S
Power connector
0.4 A
Hold-Up Battery
Lock provision
Based on the embedment of the
Harris Sierra II module
LED
On/Off/Fill/Zeroize
Package Dimensions: 2.75 x 4.5 x 7.5 inches
Weight: 3 lbs.
RF Communications | 1680 University Ave. | Rochester, NY USA 14610 | 585.244.5830 | www.harris.com
Get quotes real-time at eHarris. Order parts online at: https://premier.harris.com/rfcommsales
These item(s)/technical data have been reviewed in accordance with the international traffic in arms regulations, 22 CFR 12 – 130, and the export administration regulations, 15 CFR 730 – 774, and
determined by the export control department to be rated EAR99. General prohibitions apply. Specifications subject to change without notice. Copyright © 2009 Harris Corporation 03/09 DS-431
