GS1528 Data Sheet
2. Pin Out
2.1 Pin Assignment
1
2
3
4
8
7
6
5
SDI
SDI
SDO
SDO
GS1528
8 PIN SOIC
TOP VIEW
V
SD/HD
EE
R
V
CC
SET
Figure 2-1: 8-Pin SOIC
2.2 Pin Descriptions
Table 2-1: Pin Descriptions
Pin Number
Name
Type
Description
1,2
4
SDI, SDI
RSET
PECL INPUT
INPUT
Serial digital differential input.
External output amplitude control resistor.
6
SD/HD
LOGIC INPUT
Output slew rate control. When HIGH, the output will meet SMPTE259M
rise/fall time specifications. When LOW, the serial outputs will meet
SMPTE292M rise/fall time specifications.
7, 8
3
SDO, SDO
VEE
OUTPUT
POWER
Serial digital differential output.
Most negative power supply connection. Connect to GND.
5
VCC
POWER
Most positive power supply connection. Connect to +3.3V.
