M85045F & M49291C Military Specifications
Blolite® Blown Optical Fiber Technology (BOFT)
M49291C
PIN
M49291/6-05
M49291/7-02
General Cable
Catalog Number
OC-062H-BF-XXXX* (QPL)
OC-009S-BF-XXXX* (QPL)
Outer
Diameter
500 +/- 25um
500 +/- 25um
Fiber
Type
Multimode
Singlemode
Intended
Use
Blolite® BOF System
Blolite® BOF System
XXXX indicates color of blown optical fiber outer coating
*Blown optical fiber outer coating is available in standard colors: Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow, Violet,
Rose, Aqua
Fiber Characteristics
Intended use
MIL-PRF-49291C/7-02
Singlemode
Mil-PRF-49291C/6-05
Multimode 62.5/125
Blown Optical Fiber
Blown Optical Fiber
Type
Matched Clad
Graded Index
Mode Field Diameter
Core Diameter
Cladding Diameter
Coating Diameter # 1
Coating Diameter # 2
Coating Clad. Conc. Error
Overall Core-Clad Ratio
Attenuation:
9.2 ± .4 @ 1310 nm
8.3 µm nominal
125 ± 1 µm
N/A
62.5 ± 3 µm
125 ± 1 µm
250 ± 15 µm
500 ± 25 µm
<10.5 µm
250 ± 15 µm
500 ± 25 µm
<10.5 µm
>0.84 µm
>0.84 µm
850 nm
1300 nm
1310 nm
1550 nm
N/A
N/A
.4 dB/km
.3 dB/km
3.5 dB/km
1.0 dB/km
N/A
N/A
Bandwidth (overfill):
850 nm
N/A
N/A
>300 MHz-km
>600 MHz-km
1300 nm
Bandwidth (RML/EMBc):
850 nm
N/A
N/A
>385 MHz-km
>700 MHz-km
N/A
1300 nm
Dispersion
≤3.2 ps/nm – km @ 1310
≤22 ps/nm – km @ 1550
Refer to Specification
100 kpsi (690MPa)
N/A
Radiation Resistance
Proof Test
Refer to Specification
100 kpsi (690MPa)
