Shore2Ship™ OPNAVINST 11310.3B
Enhanced THOF-500 Shore-to-Ship Power Cable
600 V, Three Conductor, Non-Watertight, 90ºC
Filler
Conductor
Separator
Outer Jacket
Reinforcement
Inner Jacket
Conductor
Insulation
Reinforcement:
• Two reverse/open wraps of Polypropylene filament
Compliances:
Product Construction:
Conductor:
• 500 kcmil tinned copper
• OPNAVINST 11310.3B
• Jacket duty rating and physical and aging tests for
jacket and insulation per ICEA S-75-381
• Dielectric test per ICEA T-27-581
Outer Jacket:
• Extra-heavy-duty black Chlorinated Polyethylene
(CPE) – approximately 135 mils, 90˚C Rated
• Class I per ASTM B172 - 1221 wires (37 bunches of
33, unidirectional layup - .0201” wires)
• Nominal Diameter: 0.895”
Packaging:
Print:
• Per Mil Spec
Separator:
• 2 mil white Mylar separator tape pulled
longitudinally over the conductor
• GENERAL CABLE SHORE2SHIP™ 500 KCMIL
3/C 600 V ENHANCED SHORE-TO-SHIP POWER
CABLE 90˚C (YEAR OF MFG) PROPERTY OF
U.S. NAVY
Conductor Insulation:
• UV-Resistant Ethylene Propylene Rubber (EPR) –
90 mils (min avg)
Features and Benefits:
• Rated 90ºC
• Phase ID: black, white, red
• Two-layer, extra-heavy-duty reinforced jacket for
maximum protection from mechanical damage –
the cause of most portable cable failures
• Pressure extruded jacket for water resistance
• Mold-cured jacket for maximum durability
• Flexible construction for easy handling and
continuous reeling
Filler:
• Rubber filler in the center of the cable
Inner Jacket:
• Heavy-duty black Chlorinated Polyethylene (CPE) –
approximately 100 mils
• Flame- and sunlight-resistant to withstand the
environmental conditions on the pier
MINIMUM AVG.
INSULATION
THICKNESS
NOMINAL
JACKET
NOMINAL
NOMINAL
CABLE
COPPER
WEIGHT
LBS/1000 FT
(kg/km)
COND. SIZE
kcmil (STRAND)
THICKNESS
CABLE O.D.
WEIGHT
LBS/1000 FT
(kg/km)
MILITARY
PART NO.
NO. OF
COND.
CATALOG NUMBER
13333.936500
INCHES (mm)
INCHES (mm)
INCHES (mm)
OPNAVINST 11310.3B, 600 V, THREE CONDUCTOR, 500 KCMIL, NONꢀWATERTIGHT ENHANCED THOFꢀ500
11310.3B
500 (1221/24)
3
0.090 (2.29)
0.235 (5.97)
2.731 (69.37)
7563 (11255)
4761 (7085)
