6.2 USB Self Powered Configuration
Self Powered application example 1: Self powered configuration running on 5V.
Figure 6.2 Self Powered Configuration Example 1
Figure 6.2 illustrates the FT232H in a typical USB self powered configuration. A USB self powered device
gets its power from its own external power supply which is connected to VREGIN. In this application the
VREGIN is the +5V input to the on chip +3.3V/1.8V regulator. The output of the on chip LDO regulator
(+1.8V) drives pin 38, VCORE and pin 37, VCCA. The output of the on chip LDO regulator (3.3V) supplies
3.3V to the VCCIOs, VPLL and VPHY through VCCD.
Please note that when the FT232H running on +5V (VREGIN), the VCCD becomes an output.
Note that in this set-up, the EEPROM should be configured for self-powered operation and the option
“suspend on ACBUS7 low” is enabled in FT_Prog. This configuration uses the ACBUS7 pin, when this
function is enabled ACBUS7 should not be used as a GPIO in MPSSE mode.
