4.14 Modes Configurations
This section summarises what modes are configurable using the external EEPROM or the application
software.
ASYNC
Serial
UART
STYLE
ASYNC
245
SYNC
245
PARALLEL
FIFO
FT1248
ASYNC
Bit-
Bang
SYNC
Bit-
Bang
MPSSE
Fast
Serial
Interface
CPU-
Style
FIFO
FIFO
EEPROM
configured
YES
NO
NO
NO
YES
YES
NO
YES
YES
YES
NO
Application
Software
NO
YES
NO
YES
YES
YES
RESET
configured
Table 4.9 Configuration Using EEPROM and Application Software
Note:
1. The Synchronous 245 FIFO mode requires both the EEPROM and application software mode
settings
2. The application software can be used to reset the fast serial interface controller
