8A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS
SS82-LFR THRU SS86-LFR
CATHODE
FEATURES
FOR SURFACE MOUNTED APPLICATIONS
LOW PROFILE PACKAGE
BUILT-IN STRAIN RELIEF
EASY PICK AND PLACE
PLASTIC MATERIAL USED CARRIES UNDERWRITERS
LABORATORY CLASSIFICATION 94 V-0
EXTREMELY LOW VF
MAJORITY CARRIER CONDUCTION
HIGH TEMPERATURE SOLDERING: 250°C/10 SECONDS
AT TERMINALS
ROHS
MECHANICAL DATA
CASE: MOLDED PLASTIC, DO-214AB (SMC), DIMENSIONS
IN INCHES AND (MILLIMETERS)
TERMINALS: SOLDER PLATED
POLARITY INDICATED BY CATHODE BAND
WEIGHT 0.21 GRAMS
.126(3.20)
.114(2.90)
.320(8.13)
.305(7.75)
.280(7.11)
.260(6.60)
.103(2.62)
.079(2.06)
.245(6.22)
.220(5.59)
.060(1.52)
.030(0.76)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS RATINGS AT 25°C AMBIENT TEMPERATURE UNLESS OTHERWISE SPECIFIED
SINGLE PHASE, HALF WAVE, 60 HZ, RESISTIVE OR INDUCTIVE LOAD. FOR CAPACITIVE LOAD, DERATE CURRENT BY 20%
RATINGS
MAXIMUM RECURRENT PEAK REVERSE VOLTAGE
MAXIMUM RMS VOLTAGE
MAXIMUM DC BLOCKING VOLTAGE
MAXIMUM AVERAGE FORWARD RECTIFIED CURRENT
SEE FIG.1
MAXIMUM OVERLOAD SURGE 8.3ms SINGLE HALF SINE-WAVE
TYPICAL JUNCTION CAPACITANCE (NOTE 1)
TYPICAL THERMAL RESISTANCE (NOTE 2)
TYPICAL THERMAL RESISTANCE (NOTE 2)
STORAGE TEMPERATURE RANGE
OPERATING TEMPERATURE RANGE
SYMBOL SS82-LFR
V
RRM
V
RMS
V
DC
I
O
I
FSM
C
J
R
θjL
R
θjA
T
STG
T
OP
20
14
20
SS83-LFR
30
21
30
SS84-LFR
40
28
40
8.0
160
300
17
55
-55 TO + 150
-55 TO + 125
SS85-LFR
50
35
50
SS86-LFR
60
42
60
UNITS
V
V
V
A
A
PF
℃/W
℃/W
ELECTRICAL CHARACTERISTICS (A
T
T
A
=25°C UNLESS OTHERWISE NOTED)
CHARACTERISTICS
MAXIMUM FORWARD VOLTAGE AT 8.0A AND 25℃
MAXIMUM REVERSE CURRENT AT 25℃
NOTE:
SYMBOL SS82-LFR
V
F
I
R
SS83-LFR
0.55
1.0
SS84-LFR
SS85-LFR
SS86-LFR
UNITS
V
mA
0.70
1. MEASURED AT 1.0 MHZ AND APPLIED REVERSE VOLTAGE OF 4.0 V
2. P.C.B. MOUNTED 0.55”×0.55 “(14×14 mm ) 0.013mm THICK COPPER PAD AREAS
SS82-LFR THRU SS86-LFR
Page: 1
