Freescale Semiconductor, Inc.
Instruction Set
Instruction Types
Table 12-3. Jump and Branch Instructions
Instruction
Branch if carry bit clear
Mnemonic
BCC
BCS
Branch if carry bit set
Branch if equal
BEQ
BHCC
BHCS
BHI
Branch if half-carry bit clear
Branch if half-carry bit set
Branch if higher
Branch if higher or same
Branch if IRQ pin high
Branch if IRQ pin low
Branch if lower
BHS
BIH
BIL
BLO
Branch if lower or same
Branch if interrupt mask clear
Branch if minus
BLS
BMC
BMI
Branch if interrupt mask set
Branch if not equal
Branch if plus
BMS
BNE
BPL
Branch always
BRA
Branch if bit clear
BRCLR
BRN
BRSET
BSR
Branch never
Branch if bit set
Branch to subroutine
Unconditional jump
Jump to subroutine
JMP
JSR
MC68HC705C8A — Rev. 3
MOTOROLA
Technical Data
Instruction Set
