Serial Communications Interface (SCI)
SCI Operation
8-BIT DATA FORMAT
(BIT M IN SCCR1 CLEAR)
NEXT
START
BIT
START
BIT
STOP
BIT
BIT 0
BIT 0
BIT 1
BIT 1
BIT 2
BIT 3
BIT 4
BIT 5
BIT 6
BIT 7
9-BIT DATA FORMAT
(BIT M IN SCCR1 SET)
NEXT
START
BIT
START
BIT
STOP
BIT
BIT 2
BIT 3
BIT 4
BIT 5
BIT 6
BIT 7
BIT 8
Figure 10-1. SCI Data Format
10.5 SCI Operation
The SCI allows full-duplex, asynchronous, RS232 or RS422 serial
communication between the MCU and remote devices, including other
MCUs. The transmitter and receiver of the SCI operate independently,
although they use the same baud-rate generator. This subsection
describes the operation of the SCI transmitter and receiver.
10.5.1 Transmitter
Figure 10-2 shows the structure of the SCI transmitter. Figure 10-3 is a
summary of the SCI transmitter input/output (I/O) registers.
• Character Length — The transmitter can accommodate either
8-bit or 9-bit data. The state of the M bit in SCI control register 1
(SCCR1) determines character length. When transmitting 9-bit
data, bit T8 in SCCR1 is the ninth bit (bit 8).
• Character Transmission — During transmission, the transmit shift
register shifts a character out to the PD1/TDO pin. The SCI data
register (SCDR) is the write-only buffer between the internal data
bus and the transmit shift register.
MC68HC705C8A — Rev. 3
MOTOROLA
Technical Data
Serial Communications Interface (SCI)
